Wajax Equipment
Face Master 1.4
|
Length 11,800 (mm)
Width 2,400 (mm)
Tramming Height 1,400 (mm)
Working Height 1,800 (mm)
Outer Turning Radius 6,050 (mm)
Inner Turning Radius 3,370 (mm)
Weight 14,000 (kg)
Gradeability 15 (deg)
Cross-grade 8 (deg)
Max. Tramming Speed 10 (kph)
No. of Boom 1
Max. Coverage 50 (m^2)
Engine Deutz
Tramming System Hydrostatic
Boom B40L
Rock Drill Montabert
The Mechanized Drill Rig for Ultra Low Seams
Face Master 1.4 - The mechanized drill rig for ultra low seams is designed for drilling blastholes of diameters between 41 mm and 76 mm and of net length 3.2 m. The unit can be used in methane-free mineral underground workings. Design allows effective drilling of blastholes in underground workings of height up to 1.6m.
