Sefar Inc.
Fabric Circuit Board
|
This fabric is a hybrid woven fabrics consisting of PET and insulated copper monofilaments in warp and weft. It is light and highly air permeable.
This fabric is a hybrid woven fabrics consisting of PET and insulated copper monofilaments in warp and weft. It is light and highly air permeable.
The electrical components as well as the wiring structure are selected and designed by customer-specific needs. We see applications in:
Automotive industry
Architecture (interior/exterior)
Signaling
Properties of fabric circuit boad
Wire pitch: 1.0 mm and 1.27 mm (+/- 10 µm)
Resistance per wire: approx. 10 Ω/m
Electrically insulated
Light weight (< 90 g/m2, plain fabric)
High air permeability (> 8000 l/m2/s)
Highly flexible
