G-Drive Engines
|
Daewoo offers diesel models for standby and prime generator set applications. The P086TI , 8.1L in-line six-cyclinder, rated 223kW at 1800 r/min and P126TI , 11.1 L in-line six-cyclinder, rated 298kW at 1800 r/min engines are available for gensets with the capability currently of moving beyond Tier 2 emission levels. All G Drive engines beging offered (35 to 649kW) are U.S EPA Tier 1 and Tier 2 certified.
For more information click here
| Model | Type |
Disp. cc. |
Output ISO 3046 |
Weight (kg) |
||
|---|---|---|---|---|---|---|
| Cyl. | Asp. |
kW(PS)@1800rpm Standby/Prime |
kW(PS)@1500rpm Standby/Prime |
|||
| DC23 | 4 | NA | 2,238 | 24(33) / 22(30) | 19(26) / 18(24) | 210 |
| DC24T | 4 | TC | 2,370 | 32(43) / 29(39) | 26(36) / 24(32) | 240 |
| DB33 | 4 | NA | 3,268 | 35(47) / 32(43) | 29(39) / 26(35) | 310 |
| P034TI | 4 | TI | 3,268 | 60(82) / 55(75) | 48(65) / 42(57) | 335 |
| DB58 | 6 | NA | 5,785 | 70(95) / 64(87) | 59(80) / 54(73) | 450 |
| D1146 | 6 | TC | 8,071 | 105(143) / 96(130) | 85(116) / 77(105) | 720 |
| D1146T | 6 | TI | 8,071 | 138(187) / 125(170) | 118(160) / 107(145) | 780 |
| P086TI | 6 | TI | 8,071 | 223(303) / 205(279) | 199(270) / 177(240) | 790 |
| P126TI | 6 | TI | 11,051 | 298(405) / 278(378) | 272(370) / 241(328) | 910 |
| P158LE | 8 | TI | 14,618 | 443(602) / 402(547) | 414(563) / 363(494) | 950 |
| P180LE | 10 | TI | 18,272 | 540(734) / 497(676) | 496(674) / 443(602) | 1175 |
| P222LE | 12 | TI | 21,927 | 649(883) / 591(803) | 574(781) / 532(723) | 1575 |
