Specifications

• Drilling capacity
     • steel 1-1/4”
     • cast iron 1-1/2”

• Tapping capacity 3/4”
• Swing 20.8”
• Spindle nose taper MT#3
• Spindle travel 6”
• Quill diameter 3”
• Column diameter 4-1/2”
• Spindle nose to table 36.40”
• Spindle nose to base 48”
• Table size (L x W) 22” x 18.5”
• Table slot 2 @ 5/8”
• Base size (L x W) 27” x 19”
• Spindle speed
      • high 245 ~ 2000 rpm
      • low 65 ~ 540 rpm

• Motor 2 HP, 208 V, 3 Ph or 2 HP, 220 V, 1 Ph
• Coolant motor 1/8 HP / 3 Ph
• Machine weight/Gross weight 385 kgs / 430 kgs
• Packing size 1003 mm x 635 mm x 2100 mm
