MTI Mining Technologies
Drift Runner 1SB Jumbo
|
Weight: 32,800 lbs (14,900 kg)
Boom: SB Series
Boom Coverage (Height): 17’ 11″ (5.46m)
Boom Coverage (width): 17’ 11” (5.46m)
Inside Turning radius: 13ft ft. 9in. (4.19m)
Outside Turning Radius: 21’ 3” (6.48m)
Boom Guide Extension: 36” (914mm)
THE MTI Drift Runner 1 SB single Boom Hydraulic Drill Jumbo is designed for Drilling Vertical, horizontal and angled holes in underground production and Development Heading. It features one hydraulic Percussion Drifter designed to drill headings 17 – 11′ by 17 – 11″ (5.46 m by 5.46 m).
Standard Features
• MTI Montabert HC50 Hydraulic Drifter
• Intelsense II Drilling Control
• MTF Feed c/w replaceable wear strips
• Dana R20000 Series Transmission c/w Torque Converter
• EPA and MSHA Certified Engines
• One 60 HP (45KW) electric motor driving pumps for percussion/rotation
• 24v engine electric
• Large protective operators compartment
• Pilot Operated Controls
• Boom parallelism
Options
• ROPS/FOPS certified cab with sound suppression, climate control and air filtration
• HC109 Drifter (100 hp/74.5 KW electric motor)
• Optional Telescopic Canopy/Cab
• Tire Options
• Optional Cable Lengths
• Water Booster
• Air Compressor
Feed Options
• MTF 10 – 10′ (3.05m) Feed
• MTF 12 – 12′ (3.66m) Feed
• MTF 14 – 14′ (4.27m) Feed
