Dramis
Digital DECT Terminals
|
Features
• Wi-Fi Friendly
• 2 line, 24 digit LCD Display
• LCD and Key Backlight
• 4 Programmable Keys
• Automatic Channel Selection
• Auto Standby ®
• Low Battery Protection
• Wall Mountable Base and Charging Units
• Vibrating Ringer
• Adjustable Ringer
• 6 Ring Tones
• Handset/Headset/Speaker Volume
• Out of Range Detection and Alarm
• Separate Charging Stand
• Spare Charger
• 1-Key Access to Conference, Hold, Transfer and Redial
UNIVERGE SV8000 Series Digital DECT Terminals combine the benefits of digital telephony with the superior quality and features of DECT technology as an element of NEC’s UNIVERGE360 framework. These terminals help unify business communications by adding mobility options to your infrastructure.
With the addition of the DTL-RPT-1 repeater, the coverage area of your UNIVERGE Digital DECT telephone system is extended in all directions – including up and down. If the repeaters are installed so their coverage area overlaps the coverage area of the base, the base can hand-off calls to the repeaters as the user moves from one coverage area to another. When connected to the repeater, the mobile handset operates exactly as it does when connected to the base. Hand-off from the base to the repeater is imperceptible to the user, even during an active call.
This wireless system provides perfect voice quality, seamless handover and a secure air interface that protects your company’s investments in existing telephones, applications and your network infrastructure.
DIGITAL DECT TERMINALS BENEFITS
Improve customer satisfaction
Offering customers a quick, direct way to reach your employees without jumping through hoops improves customer satisfaction rates. Digital DECT enables your company to deliver this level of service by providing workers a way to be reached – even while they are away from their desks.
Increase productivity
By giving your employees the ability to access communications features while away from their desks, you enable them to complete multiple tasks simultaneously. And because your employees can answer calls directly, reception workers and administrative assistants are free to complete other work.
Reduce customer costs
Because most calls can be answered immediately, callback charges are minimized. Additionally, no internal call costs are associated with Digital DECT Terminals. These terminals provide the optimal approach for flexible businesses. A single converged network can be used to provide both fixed and wireless telephony and reduce dedicated cabling requirements. Move, add and change costs in addition to cabling expenditures are reduced.
Select a secure, easy-to-install solution
Installing Digital DECT is easy, and your data and network are secure. All communications are encrypted to protect the privacy of both you and your customers. Digital DECT also provides feature transparency on NEC platforms and a host of additional features.
Specifications
Specifications
Compliance: FCC and IC part 15
RoHs: Yes
Frequency: 1.9G (1920~1930 MHz) DECT 6.0
Audio Process: Digital (ADPCM)
Operating Temperature: 0°~ +50°C
Transmission: TDMA/TDD
Channels: 5
ID Combinations: 130,000
Features: Wi-Fi Friendly
6 Ring Tones
LCD and Key Backlight
4 Programmable Keys
Auto Channel Selection
Auto Standby ®
Low Battery Protection
Wall-Mountable Base and Charging Units
Vibrating Ringer
Adjustable Ringer
2 line, 24 digit LCD Display
Handset/Headset/Speaker Vol.
Out of Range Detection & Alarm
Separate Charging Stand
Spare Charger
1-Key Access to Conference, Hold, Transfer and Redial
BASE UNIT
Receive/Transmit Frequency: 1920 ~ 1930 MHz
Power Requirements: 10 V from supplied AC adapter
Size: 58mm (H) x 215mm (D) x 130mm (W)
Weight: 410g
HANDSET
Receive/Transmit Frequency: 1920 ~ 1930 MHz
Power Requirements: Nickel-Metal Hydride battery pack
Size: 163mm (H) x 31mm (D) x 55mm (W)
Weight: 150g (Handset = 120g + Battery pack = 30g)
Battery Capacity: 910 mAh, 2.4V
Talk Mode: 16 hours (typical)
Standby Mode: 7 days (typical)
DTL-RPT-1 REPEATER
AC Power Adapter Input: 120 V, 50-60 Hz, 90 mA (RJ-11)
AC Power Adapter Output: 5 V dc , 620 mA
Frequency Band: 1880MHz - 1900MHz
Transmit Power: 240mW (+24dBm)
Receiver Sensitivity: <-92 dBm at 10-3 BER
Standard: DECT
Features: Up to 6 repeaters per base
Low power consumption
Verifies repeater connection
Up to 3 repeaters in sequential or daisy-chain layout
