Industrial Diesel Products
TH125R-1
|
Specific Characteristics:
• Made in the USA
• UL recognised component
• BONDS to Oil Pan or Fluid Reservoir
• RAISES Oil Temperature to Operating Levels
• IMMEDIATE Oil Pressure Throughout Engine
• IMPROVES Crankability
• EXTEND Starter Motor Life
• REDUCES Cold Start Wear
• WARMS Important Internal Parts
• REDUCES System Warm-up Time
• NO Maintenance
• IDEAL for Hydraulic Tanks
• WILL NOT Burn Out Like Immersion Oil Sump Heaters
• Electrical cord length 6 feet with sealed three point plug
TITAN Pad Heaters are 0.075" (1.9mm) thin flexible heating pads that are attached to the outside of an oil pan or metal fluid reservoir such as a hydraulic tank. The pad incorportes a special "hi-tech" peel back adhesive on one side that bonds onto the metal surface. Once installed, the heater pad will never fall off.
TITAN Pad Heaters are supplied with an installation kit and instructions for a complete installation; no special tools or skills are required.
Width: 3.0 inches diameter Inches Weight: 0.5 lbs Output Power: 125 Watts Amps: 1.1 amps Voltage (Volts) 120 volts a.c. Gas Engine Capacity: 2-4 US Quarts Diesel Engine Capacity: 2-4 US Quarts Auto/Manual Transmission: 2-16 US Quarts Hydraulic Tank Engine Capacity: 4-40 US Quarts Water Tank Capacity: 20-100 US Quarts
Three Year Warranty
Take note of the following critical criteria before installaion.
Incorrect installation of the TITAN pad heater will void the warranty.
• Sand and clean the application area.
Three Year Warranty
Site Preparation
Take note of the following critical criteria before installaion.
• TITAN heaters can only be installed on a metal surface; steel, aluminum and cast Iron.
• The application area must have a smooth flat surface, no bumps, ridges or indentations; the pad must make 100% contact with the surface.
• Remove dirt, grease, oil and paint from the installation area with a cleaning agent that does not leave any oil film on the surface.
• Do not trim or cut the TITAN heater pad.
• Warm the engine to raise the oil pan temperature.
• The TITAN pad heater has an adhesive backing, do not use any other adhesives to apply the pad.
Incorrect installation of the TITAN pad heater will void the warranty.
Installation
• Sand and clean the application area.
• Peel off the backing and warm the pad for three seconds to heat the adhesive; apply the pad to the surface area.
• Weatherproof the outer edge of the pad with the, supplied, high temperature silicone adhesive.
• Route the electrical cord with whe aid of the, supplied, cable ties to the location where the plug is to be positioned for connection to the AC extension cord.
