HI Mining Pty Ltd.
Pusher Leg (DOUBLE)
|
The reliability and power of hydraulic energy and the finest control allowing for a consistent penetration rate to be maintained.
More information
Characteristic
Part Number: PL4000 - (2000-2SA, 2000-2SB, 2000-2SC)
The reliability and power of hydraulic energy and the finest control allowing for a consistent penetration rate to be maintained.
Features:
- Lightweight
- Quick release coupling for fast assembly / dis-assembly
Description
HI Mining has developed the most advanced Pusher/Jack Leg available on the market. We have legs in various sizes and offer both single and double stage legs. These legs come with the pressure management system fitted and are manual retract for safe operation.
Sizes Available (retracted length):
- 1.4m-56″ – PL 4000-2000-2S-SA
- 1.1m-46″ – PL 4000-2100-2S-SA
- .85m-36″ – PL 4000-2200-2S-SA
Our pusher legs come fitted with quick release coupling for fast assembly and dis-assembly and are light weight for easy transportation. With our patented flow management the hydraulic legs give fine and accurate control allowing for consistent pressure on the drill steel.
Used in conjunction with the HE-22 HustlerTM HS 4000-3000 the HI Mining pusher/jack legs require 38l/min and can run from any hydraulic energy source or one of our Power Packs MPP 4000-4000 or TBC 4000-4200.
