Solid State Relays

Relays are an electrically activated switch that shortens the distance current has to travel from the battery to whatever device is being powered. This ensures that the optimum amount of current is efficiently delivered to lights, horns, or any other accessory.

In choosing the appropriate relay, consult the formula to determine what size relay you require. Step up one level from the indicated amperage load.

Formula: Total Watts ÷ Voltage = Required Amperage Example: 2 X 55 W =110 ÷ 12V = 9.17 Amps

Use a 20 Amp Relay

Solid State Relays

Part# 41005 12V, 30A, SPST, Bulk 10

Also Available w/ Tab (Part# 41010)

Available in, 24V, 20A (Part# 42005)

Part# 41015 12V, 40A, SPST, Dual Output, Bulk 10

Also available w/Tab (Part # 41020)

Part# 41025 12V, 40A, SPST, Bulk 10

Also available w/Tab (Part# 41030)

Part# 41035 12V, 40A, SPST, Skirted, Waterproof,

Bulk 10

Part# 41040 12V, 6A, Solid State

Also available in 12V 12A (Part# 41045)

Part# 41050 12V, 80A, SPST, Screw Terminals w/Tab

Also available in 24V, 60A, SPST

Part# 41055 12V, 20A, Solid State

Also available in 12V, 40A (Part # 41060)

Part# 41065 12V, 70A, SPST, Heavy Duty w/Tab

Part# 41075 12V, 40A, SPDT, Diode Suppressed

Part# 41085 12V, 70A, SPST, Heavy Duty

Part# 41090 Jamb switch, 6 contact Jamb switch female

Part# 41092 Magnet&Detection switch assembly 0.5” range

Part# 41095 Jamb switch, 6 contact jamb switch male

Part# 41105 Timer, 12V, 30 second light timer with

relay

Part# 41106 Timer, 12V, 30 second dimmer timer module

Part# 41110 Timer, 12V, 12 minute mirror heater timer

Part# 41115 Timer, 12V, 2 minute door timer

Part# 41120 12V, Solid State, 6V detection relay

Part# 41121 12V Time delay module (30 seconds)

Part# 41125 Logic module, 12V, 2A, Solid State,

Brake CHMSL logic module

Part# 41130 12V, 40A, SPDT
