PERI Formwork Systems Inc.
PEP 20 Props
|
Galvanized slab props made of steel tubing with well-engineered details for fast forming. The low weight combined with a high load-bearing capacity makes these steel props very cost-effective.
Advantages
• High loading capacity
Low weight but with a high loading capacity
PEP 20-300: G=15.9 kg perm. F=20.0 kN (according to EN1065 when fully extended)
• Adjusting nut
Adjusting nut with a new type of lowering nib and tie rod adjustment.
• Stamped measuring scale
For faster adjustment of the prop length. Numbers stamped on the inner tube show the total length in increments of 100 mm.
• Easy assembly of accessories
The prop heads are centered by means of the same end plates on the inner and outer tubes. Thus, the PEP prop can be “turned on its head” without any problems and is easy to use.
