SolidCAD, a division of Solid Caddgroup Inc.
RVT 2 DWG Suite
|
The RVT 2 DWG Suite is a line of conversion utilities (which includes processes as well) that allows users to convert an Autodesk® Revit® Model to a standard Autodesk® AutoCAD® DWG file format. We use the Revit Export to CAD option that is built into Revit of course, but our conversion utilities much further and have been customized for different Federal and Provincial Government Dept. as well as for commercial client usage. RVT 2 DWG is currently available in 5 different Standards; PWGSC Atlantic, PWGSC NCA, PWGSC Ontario, DND CAD Standards and NS DTI (Nova Scotia Department of Transportation and Infrastructure).
NS DTIR (NOVA SCOTIA DEPARTMENT OF TRANSPORTATION AND INFRASTRUCTURE RENEWAL)
RVT 2 DWG (NS DTI) is relatively new to us and is currently being used by one of our Revit clients in Nova Scotia. It includes Revit NSDTIR Template, Titleblocks, Elevation, Section and Detail call outs as well, with more families to come in the near future. It currently works with Revit and AutoCAD 2014 and up.
PWGSC ATLANTIC, VERSION 7.0 OF QA CHECK
The PWGSC Atlantic version has been available and in use in Atlantic Canada since 2012. It’s been tested over and over by consultants that are using Revit and need to provide PWGSC with DWG files that pass the PWGSC Atlantic, version 6.0 QA Check (and previous version as well). RVT 2 DWG (PWGSC Atlantic) currently works with Revit and AutoCAD 2013 and up.
PWGSC NATIONAL CAPITAL AREA (NCA), VERSION 8.0.0 OF QAR CHECK
The PWGSC NCA version has been available and in use since early 2014 and is being tested and used for PWGSC NCA projects as we speak. It includes a Revit NCA Template, Titleblocks, Elevation, Section and Detail call outs as well, with more families to come in the near future. RVT 2 DWG (NCA) currently works with Revit and AutoCAD 2013 and up.
PWGSC ONTARIO, VERSION 8.0.0 OF QAR CHECK
The PWGSC Ontario version has been available and in use since 2017. It is being used for PWGSC Ontario projects as we speak. It includes a Revit PWGSC Ontario Template, Titleblocks, Elevation, Section and Detail call outs as well, with more families to come in the near future. RVT 2 DWG (PWGSC Ontario) currently works with Revit and AutoCAD 2013 and up.
DEPARTMENT OF NATIONAL DEFENCE (DND STANDARDS)
The RVT 2 DWG DND Standards version has been available and in use in Canada since early 2017. So it’s been tested by consultants that are using Revit and need to provide DND with DWG files that pass the DND Checker. RVT 2 DWG (DND) currently works with Revit and SolidCAD 2014 and up.
